Hastelloy B2 Ball Valve

Home > Hastelloy > Hastelloy B2 Ball Valve

From Hamilton, New Zealand, Mason Tubefittings has built a strong reputation for supplying robust industrial components, with the Hastelloy B2 Ball Valve standing as a prime example of their commitment to quality. This valve is meticulously engineered for the most challenging environments, offering a reliable solution where lesser materials would quickly fail. We understand that durability and precise performance are non-negotiable, which is why this particular valve is crafted to deliver exceptional service and long-term reliability in critical systems.

Hastelloy Alloy 3 Way B2 Ball Valve in Hamilton, New Zealand, Hastelloy 4 Way B2 Ball Valve Price in Auckland, UNS N10665 Hastelloy 5 Way B2 Ball Valve Supplier in Tauranga, Hastelloy High Pressure B2 Ball Valve Price List in Wellington, Hastelloy Instrumentation B2 Ball Valve Manufacturer in Hamilton, DIN 2.4617 Hastelloy Alloy Compression B2 Ball Valve in Dunedin, Hastelloy Hydraulic B2 Ball Valve Supplier in Tauranga, Hastelloy High Pressure B2 Ball Valve Price List in Hamilton, Hastelloy 2 Way B2 Ball Valve Price in Dunedin

The integrity of the Hastelloy B2 Ball Valve comes from its unique composition, primarily a nickel-molybdenum alloy that provides outstanding resistance to hydrochloric acid at all concentrations and temperatures. This material offers excellent strength and toughness, maintaining its mechanical properties even in high-temperature settings. It’s this robust combination of a specialized alloy and superior engineering that gives the valve its ability to withstand significant pressure and corrosive attack without compromising its structural integrity.

Hastelloy B2 Ball Valve Specifications

STANDARD	ASTM A494 / ASME SA494 API 600/BS1414, ASME B 16.34, ASME B 16.10, ASME B 16.5, API 598/BS EN 12266-1,ASME B 16.25
VALVE SIZE	1/8″ TO 2″ / 6 MM TO 50 MM
THREAD	NPT, BSPP, BSPT, JIC, METRIC, UNF
CONNECTION	THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE
FUNCTION	2 WAY, 3 WAY, 4 WAY, 5 WAY,
PRESSURE RATING	1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15000 PSI, 20000 PSI
SEAL RING MATERIAL	PTFE, PVDF, DELRIN, PEEK, GRAPHITE
STANDARD	ISO , DIN , ANSI , API , ASME , AWWA , MSS ,
MEDIA	HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL
MEDIA TEMPERATURE	(-120* C TO 500*C )RANGE AS PER PRESSURE
BODY TYPE	BAR STOCK
PACKING DETAILS	BOX PACKING, WOODEN PALLET
APPLICATION	MATERIAL HANDLING EQUIPMENT, EARTH MOVING MACHINERIES , POWER GENERATING PLANT , STEEL MANUFACTURING PLANT , MINING INDUSTRIES , CHEMICAL PROCESSING MACHINES , PIPING LINE , PAINT INDUSTRIES , TRUCKS AND TRAILERS , AUTOMATION , AGRICULTURE MACHINES , AEROSPACE & DEFENCE EQUIPMENTS,

Hastelloy B2 Ball Valve Chemical Composition

Hastelloy B2	Ni	C	Mo	Mn	Si	Fe	P	S	Co	Cr
Hastelloy B2	Balance	0.02 max	26.0-30.0	1.0 max	0.10 max	2.0 max	0.040 max	0.030 max	1.0 max	1.0 max

Hastelloy B2 Ball Valve Mechanical Properties

Density	Melting Point	Yield Strength (0.2%Offset)	Tensile Strength	Elongation
9.2 g/cm3	1370 °C (2500 °F)	Psi – 51,000, MPa – 350	Psi -1,10,000, MPa -760	40 %

Hastelloy B2 Ball Valve Equivalent

STANDARD	UNS	WERKSTOFF NR.
Hastelloy B2	N10665	2.4617

Top Hastelloy B2 Ball Valve Manufacturing Company in Hamilton

At Mason Tube Fittings, we are the largest supplier, manufacturer, and exporter of Hastelloy B2 Ball Valve in Hamilton, New Zealand. Our advanced manufacturing facilities, strategically positioned in the New Zealand, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfil your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.

Types of Hastelloy B2 Ball Valve

Hastelloy Alloy 2 Way B2 Ball Valve Supplier in Tauranga, Hastelloy 3 Way B2 Ball Valve in Hamilton, New Zealand, Hastelloy Alloy 3 Way B2 Ball Valve Price List in Hamilton, UNS N10665 Hastelloy 5 Way B2 Ball Valve Price in Dunedin, Hastelloy Instrumentation B2 Ball Valve Price in Auckland, DIN 2.4617 Hastelloy Compression B2 Ball Valve Supplier in Tauranga, Hastelloy Hydraulic B2 Ball Valve Manufacturer in Hamilton, Hastelloy Alloy High Pressure B2 Ball Valve in Dunedin

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Manufacturer and Supplier of Hastelloy B2 Ball Valve in Hamilton, New Zealand

Mason Tube Fittings is a leading supplier and stockist of premium Hastelloy B2 Ball Valve in Hamilton, New Zealand. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Hastelloy B2 Ball Valve Uses

You will typically find the Hastelloy B2 Ball Valve hard at work in some of the most demanding sectors, such as chemical processing, pharmaceutical production, and waste treatment plants. Its exceptional resistance to hydrochloric and sulfuric acids makes it indispensable for handling aggressive media, controlling the flow in reactors, piping systems, and purification units. This valve is the go-to choice for engineers who need absolute reliability when managing highly corrosive fluids, ensuring process safety and efficiency where failure is simply not an option.
