Here in Hamilton, Mason Tubefittings is proud to support New Zealand’s industries as a trusted local manufacturer and supplier of high-performance fluid control solutions. Our dedication to local craftsmanship shines through in products like our reliable PP Ball Valve. We understand the critical need for durable and corrosion-resistant components, which is why we produce this valve to exacting standards, ensuring it stands up to the demanding conditions found in a wide range of commercial and industrial applications across Aotearoa.

PP ball valve Manufacturer In Hamilton, PP ball valve In Tauranga, PP ball valve Auckland, PP ball valve Dunedin. PP ball valve Jebel Ail, PP ball valve Supplier In Hamilton, New Zealand.

Crafted from solid polypropylene, this ball valve offers a distinct advantage in handling aggressive chemicals. Its composition gives it a remarkable resistance to a wide spectrum of corrosive substances, from strong acids and alkalis to various solvents. This inherent toughness is paired with excellent mechanical strength, creating a valve that is not only chemically inert but also built to withstand significant system pressures and mechanical stress, guaranteeing a long and dependable service life in challenging environments.

PP Ball Valve Specifications

Material Of Construction	Unplasticized Poly Vinyl Chloride	Construction	Multi Piece Body
Design	Single body moulded	Test pressure	07 kg./cm2
Max working temp	60 c (consistently)	Size Range	15 m to 80 mm
Connection End	Solid Plain and Ball Valve	Standard	As per requirement

PP Flange End Ball Valve Material of Construction

Material Specification
No.	DESCRIPTION	QTY.	MATERIAL
1)	Flanged end	2	PP / HDPE & PVDF
2)	Body	1	PP / HDPE & PVDF
3)	Ball	1	PP & PVDF
4)	Stem/Spindal	1	Polypropylene With M.S. /S.S
5)	Seat Ring	2	PTFE (TEFLON)
6)	Body”O”Ring	2	Neoprene
7)	Stem Seal Ring	1	PTFE (TEFLON)
8)	Stem “O” Ring	1	Neoprene
9)	Stud, Nut & Washer	REQ	M.S. Zinc Plated/S.S
10)	Nut Cap	REQ	Polypropylene.
11)	Handle	1	M.S. PP Coated.
12)	Handle Hex. Pin	1	M.S./ S.S.
13)	Handle Cap	1	Polypropylene.

Polypropylene Flange End Ball Valve Dimensions

Size		L	T	OD	ID	H1	H
In.	MM
1/2″	15MM	129	12.5	100	13.5	130	69
3/4″	20MM	142	14	101	19	131	75
1″	25MM	160	20	123	24	165	89
1 1/2″	40MM	182	20	140	38	197	109
2″	50MM	208	22	165	50	200	121
2 1/2″	65MM	230	25	185	63	255	144
3″	80MM	251	25	201	75	255	150
4″	100MM	302	28	228	100	350	182
6″	150MM	428	30	300	150	–	236
8″	200MM	505	32	360	201	–	325
10″	250MM	570	34	425	242	–	310
12″	315MM	590	35	487	300	–	309

Top PP Ball Valve Manufacturing Company in Hamilton

At Mason Tube Fittings, we are a leading supplier, manufacturer, and exporter of PP Ball Valve in Hamilton, New Zealand. Our state-of-the-art manufacturing facilities, strategically located in the New Zealand, enable us to deliver high-quality solutions that meet your specific requirements. With a comprehensive inventory of Monel materials, we are well-equipped to fulfill your needs efficiently. Our commitment to excellence and customer satisfaction ensures that we consistently maintain a ready stock of Monel Manifold Valves to support your operational demands.

Types of PP Ball Valve

PP ball valve Manufacturer In Hamilton, PP ball valve In Tauranga, PP ball valve Auckland, PP ball valve Dunedin. PP ball valve Jebel Ail, PP ball valve Supplier In Hamilton, New Zealand.

Largest Manufacturer and Supplier of PTFE Ball Valve in Hamilton, New Zealand

Mason Tube Fittings is a leading supplier and stockist of premium PTFE Ball Valve in Hamilton, New Zealand. Our products find extensive application across diverse industries, and we are dedicated to delivering outstanding service while ensuring high customer satisfaction. Our specialized finishing techniques distinguish us in the metal industry, enhancing the performance and durability of our valves. We are committed to consistently providing top-quality Monel Manifold Valves while effectively addressing the unique needs of our customers.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

PTFE Ball Valve Uses

The versatility of the PP Ball Valve makes it a perfect fit for numerous applications, particularly where corrosion is a primary concern. You’ll find it performing reliably in chemical processing plants, water treatment facilities, and aggressive effluent systems. It’s equally at home in agricultural irrigation, pharmaceutical production, and laboratory settings. Its simple quarter-turn operation provides easy and immediate flow control, making it a go-to component for engineers and technicians who need a robust, maintenance-free solution for managing demanding fluids.
