From the heart of Hamilton, New Zealand, Mason Tubefittings stands as a trusted local source for precision-engineered flow control solutions. We take pride in manufacturing and supplying robust industrial components, with our Stainless Steel 316ti Ball Valve being a prime example of our commitment to quality. Designed to meet the demanding needs of various sectors, this valve is built for reliability and longevity, offering peace of mind in applications where failure is not an option. It’s a product that reflects our dedication to supporting New Zealand industry with superior, locally accessible products.
The exceptional strength of this ball valve starts with its material. Stainless Steel 316ti is a grade enhanced with titanium, which gives it a significant advantage in resisting corrosion, particularly in environments prone to sensitization like welding. This composition ensures the valve maintains its integrity and mechanical properties even when exposed to high temperatures. The result is a component that is not only tough and durable but also highly resistant to pitting and crevice corrosion, making it a fundamentally reliable choice for controlling flow under challenging conditions.
| VALVE SIZE | 1/8″ TO 2″ / 6 MM TO 50 MM |
| THREAD | NPT, BSPP, BSPT, JIC, METRIC, UNF |
| CONNECTION | THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE |
| FUNCTION | 2 WAY, 3 WAY, 4 WAY, 5 WAY, |
| PRESSURE RATING | 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15000 PSI, 20000 PSI |
| SEAL RING MATERIAL | PTFE, PVDF, DELRIN, PEEK, GRAPHITE |
| STANDARD | ISO , DIN , ANSI , API , ASME , AWWA , MSS , |
| MEDIA | HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL |
| MEDIA TEMPERATURE | (-120* C TO 500*C )RANGE AS PER PRESSURE |
| BODY TYPE | BAR STOCK |
| BRAND NAME | TU-LOK |
| PACKING DETAILS | BOX PACKING, WOODEN PALLET |
| EQUIVALENT BRANDS | SWAGELOK, PARKER, DK-LOK, HAMLET, OLIVER VALVES, HOKE |
| APPLICATION | MATERIAL HANDLING EQUIPMENT, EARTH MOVING MACHINERIES , POWER GENERATING PLANT , STEEL MANUFACTURING PLANT , MINING INDUSTRIES , CHEMICAL PROCESSING MACHINES , PIPING LINE , PAINT INDUSTRIES , TRUCKS AND TRAILERS , AUTOMATION , AGRICULTURE MACHINES , AEROSPACE & DEFENCE EQUIPMENTS, |
Grade | C | Ni | Si | N | S | Mn | P | Cr | Mo | |
SS 316Ti | min. | – | 10.0 | – | – | – | – | – | 16.0 | 2.00 |
max. | 0.08 | 14.0 | 0.75 | 0.10 | 0.030 | 2.0 | 0.045 | 18.0 | 3.00 | |
Grade | Tensile Strength (MPa) min | Elongation (% in 50mm) min | Yield Strength 0.2% Proof (MPa) min | Hardness |
Rockwell B (HR B) max | ||||
SS 316Ti | 515 | 35 | 205 | 75 |
STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
SS 316Ti | S31635 | 1.4571 | Z6CNDT17‐12 | X6CrNiMoTi17-12-2 | SUS 316Ti | 320S31 | 08Ch17N13M2T |
Contact us to get a quick quote for your requirement.
You’ll find this valve is incredibly versatile, ideally suited for demanding applications across diverse fields. It performs exceptionally well in chemical processing plants, where it handles aggressive acids and solvents, and is equally at home in pharmaceutical or food production environments due to its easy-clean surfaces. Its resistance to high temperatures also makes it a perfect fit for marine applications, offshore platforms, and high-temperature water systems. Essentially, wherever corrosion resistance and dependable performance are critical, the 316ti ball valve from Mason Tubefittings provides a trusted, long-lasting solution for your most crucial operations.
Please feel free to contact us if you need any further information or for enquiry.
